SMD Strip-RV0090DC
90 LEDs/m-24V-10mm-4.8W/m-220lm/W Ultra-high luminous

Ultra-high luminous efficacy of 220 lm/W for enhanced energy efficiency and environmental sustainability

Features 3235 large-size dual-chip high-efficiency LED chips for exceptional brightness and extended lifespan, backed by an ultra-long 5-year warranty.

FPC double-sided board with 3 oz copper thickness, minimal end-to-end voltage drop, and superior heat dissipation.

Application :

Ambient Decorative Lighting: Suitable for residential homes, hotels, commercial spaces and similar scenarios.

Accent Lighting: Ideal for wardrobes, furniture, display cabinets and similar applications.

Linear Lighting Source: Compatible with aluminum profiles of various sizes and specifications, suitable for outdoor decorative lighting.

Contact Us
Poster
Parameter
Video
Accessories
Message

Product Poster



Technical Parameter

P/N LED Color CCT (K) CRI SDCM Beam Angle(°) Luminous Flux(Lm/m) Luminous Efficacy (Im/w) Voltage(DC V) Power(W/m)
RV0090DC White 2700K ≥80 ≤5 ≥115 1008 210 24 4.8
RV0090DC White 3000K ≥80 ≤5 ≥115 1008 210 24 4.8
RV0090DC White 4000K ≥80 ≤5 ≥115 1056 220 24 4.8
RV0090DC White 5000K ≥80 ≤5 ≥115 1056 220 24 4.8
RV0090DC White 6500K ≥80 ≤5 ≥115 1008 210 24 4.8

Accessories

Dimmer
Dimmer

 Model: KQ1CH-016-A01

 Input Voltage (Receiver): DC12/24V

 Working Voltage (Remote Controller): 3VDC(CR2032 Botton Cell)

 Output Type: PWM output, Constant Voltage

 Output Current: 1 Channel,≤8A per channel

 Output Power: 12V<96W ,24V<192W

 Output Signal: 2.4GHz

 Light: Single Color

 Control Sector: Single Sector

 Standby time: 12 Months

 Control Distance: 30 Meters

Cable-Board Connector
Cable-Board Connector
Application: 8mm

Model:  1CN-07-117

Cable-Board Connector
Cable-Board Connector
Application: 8mm

Model:  1CN-07-123
